KA49702A

KA49702A are 1-chip battery monitoring IC for Li-ion battery cells, which have built-in high-resolution ADCs and can measure the voltage and current levels of battery cells with high accuracy. The IC can support applications with up to 17 battery cells connected in series or applications with a maximum voltage of 85V, contributing to the miniaturization of battery management systems. KA49702A achieves a voltage measurement accuracy +/-2.9mV, the highest standard in the industry. Additionally, the IC can support a high-side switch as a charging and discharging relay switch control.

Specification

PDF iconProduct Brief

Item Performance characteristics
Category Non Stackable
Package QFP-48
Number of Channels 17
Operating Voltage [Min] (V) 12.5
Operating Voltage [Max] (V) 85
Interface SPI
Voltage Accuracy (mV) ±2.9
Operating Temperature [Min] (°C) -40
Operating Temperature [Max] (°C) 105
QFP-80_N_S

Support tool

We provide information, evaluation tools, etc. to support your design. Please feel free to contact us.
