I3810YYI is a high-performance Digital ChipCorder^® device designed for external SPI flash-based audio playback with 3-channel mixing.

I3810YYI can be operated under SPI mode, I²C mode, or GPIO trigger mode. Audio playback sources include external SPI flash, I²S interface, or direct SPI data from the MCU. With 28-bit flash space addressing, it can support up to 2Gbit NOR flash. With multiple compression algorithms, it can support sample rates up to 48kHz.

A built-in high-efficiency, filter-free Class-D amplifier delivers up to 3.0W with 4Ω or 1.7W with 8Ω based on 5 V speaker power supply.

Target Applications:

• Home Appliances
• Smart Home Devices
• Industrial & Safety System
• Consumer Electronics
• Commercial Equipment



Key Features:

Duration / Flash Storage

• 1092min (18.2hr) playback time based on 8kHz/4bit ADPCM algorithm
• 46min playback time based on 48kHz/16bit PCM algorithm
• 28-bit flash addressing for up to 2Gbit
• Pass-down command for direct access to external flash memory



Audio Management

• Voice Prompts - Store pre-recorded audio
• Voice Macros - Execute pre-programmed macro scripts



Sample Rate

• Two internal master sample rates: 32kHz / 48kHz
• 4 / 5.3 / 6.4 / 8 / 10.67 / 12.8 / 16 / 32kHz based on 32kHz master sample rate
• 6 / 8 / 9.6 / 12 / 16 / 19.2 / 24 / 48kHz based on 48kHz master sample rate



Audio Output

• Analog Class-D speaker driver
• Capability of driving 4Ω speaker directly
• 3W @ 5V 4Ω
• 1.7W @ 5V 8Ω



I/O Interfaces

• 1 set of SPI interface / I²C interface
• 8 GPIOsmultiplexed with alternate functions



Operating Characteristics

• Voltage range: 2.7V ~ 5.5V
• Temperature range: -40°C ~ +105°C



Package

• QFN-32 (5 x 5mm²)
