KA49703A is an IC for lithium-ion battery measurement and monitoring. It incorporates a high-resolution ADC, enabling highly accurate measurement of battery cell voltages and current levels.Despite its compact 48-pin QFP package, the device can monitor up to 16 battery cells. It also features a daisy-chain function that supports up to 55 devices connected in series, making it ideal for high-voltage applications such as battery backup units for AI server and large-scale energy storage systems.In addition, KA49703A achieves a voltage measurement accuracy with a maximum error of ±2.9 mV and includes alarm output functions for detecting overcharge, overdischarge, and abnormal high- or low-temperature conditions.KA49703A contributes to improved safety, higher quality, reduced size, and lower power consumption in Battery Management Systems (BMS).

Specification

Datasheet

Item	Performance characteristics
Category	Stackable
Package	QFP-48
Number of Channels	16
Operating Voltage [Min] (V)	12.5
Operating Voltage [Max] (V)	76.8
Interface	SPI / Daisy
Voltage Accuracy (mV)	±2.9
Shutdown Current (μA)	5.0
Operating Temperature [Min] (°C)	-40
Operating Temperature [Max] (°C)	105

Recommended Circuit

Support tool

We provide information, evaluation tools, etc. to support your design. Please feel free to contact us.

 Evaluation Board
