In-cabin Sensing
For safety, the demand for in-cabin sensing is expanding in response to stricter safety tests and regulatory requirements.
For comfort, personalized user experiences are being driven by individual identification and state recognition.
Inside the cabin, occupant monitoring, face recognition, gesture control, and precise object detection work reliably under any ambient lighting conditions.
Why Nuvoton TOF?
Nuvoton's 3D sensing technology provides accurate depth maps essential for modern smart cockpits. Our Time-of-Flight sensors are designed to perform reliably under challenging lighting conditions, from bright sunlight to complete darkness, ensuring continuous monitoring of driver alertness and occupant safety.
- Pulse-ToF Technology: High ambient light immunity (up to 120k lux) and global‑shutter clarity ensure stable, blur‑free depth sensing.
- On-Chip ISP (Depth Processing): Integrated depth engine facilitates real-time data processing and low-latency measurement.
- Simultaneous Capture: Synchronized acquisition of Depth and NIR (2D) images for multi-modal sensing.
- AEC‑Q100 Grade 2 Qualification: Designed to operate reliably in demanding automotive environments.
- Functional Safety: Supports safety‑critical applications with ASIL‑B compliance.
Applications
Gesture control
Captures blur-less images of the fast-moving objects
Simple, touchless spatial operation
Privacy protection
Real-time measurement of human posture/position
Privacy protection meets safety by 3D data
Facial recognition
Simultaneous 2D/3D sensing at the same angle
Prevents photo spoofing by Stable 3D recognition
Occupant monitoring (OMS)
Head position / Movement / Position recognition
Head position / Seat height / Airbag control
Sound control
Postured-based audio optimization
Head position detection / Sound field control
System block diagram
Detailed Specs
Click on block in the diagram
to view relevant IC solutions.
